Pharmaceutical Industry
Overview
Premium quality thermoformable PVC films designed for the packaging of pharmaceutical products, photosensitive and hygroscopic.
Non-toxic Rigid PVC
Clear and color rigid PVC film:
Description
Material manufactured with the highest quality, designed to be processed in thermoforming equipment to produce blister packs suitable for use as primary packaging for pharmaceuticals.
Technical information
- Non-toxic.
- UV protection (upon customer request).
- Maximum transmittance of 10% in the 290 – 450 nm range (applicable only to certain colors).
- Quality certificate for each batch.
- Sealable with aluminum.
- FDA DMF# 17508.
- 250 – 500 μm
- Upon customer request
- WVTR 5 g/m²/day max @ 38°C, 90% RH
Pharmaplami Premium
Clear and color rigid PVC film for high speed machines:
Description
Premium plastic films are designed for use in high-speed thermoforming equipment to produce blister packs suitable for pharmaceutical packaging.
Technical information
- Non-toxic.
- UV protection (upon customer request).
- Maximum transmittance of 10% in the 290 – 450 nm range (applicable only to certain colors).
- Quality certificate for each batch.
- Sealable with aluminum.
- FDA DMF# 17508.
- Enhanced productivity on high-speed equipment.
- 250 – 500 μm
- Upon customer request
WVTR 5 g/m2/day max @ 38°C, 90% RH
Thermoforming temperature suggestion
130-150 °C
Non-toxic MPH
High barrier PVC/PVdC clear and color film:
Description
MPH materials manufactured by Plami feature five levels of moisture protection through multiple PVdC layers, making them suitable for thermoforming to produce blister packs for pharmaceutical packaging.
Technical information
- Non-toxic.
- UV protection (upon customer request).
- Maximum transmittance of 10% in the 290 – 450 nm range (applicable only to certain colors).
- Quality certificate for each batch.
- Sealable with aluminum.
- FDA DMF# 17508.
- 250 – 500 μm
- Upon customer request
PVdC deposition transmissions:
PVdC (g/m2): | 32 | 40 | 60 | 90 | 120 |
WVTR*: | 1.4 máx | 0.8 máx | 0.6 máx | 0.4 máx | 0.3 máx |
*g/m2/day @ 38°C, 90%RH
MPH Pharmaplami Premium
High barrier PVC/PVdC clear and color film for high speed machines:
Description
High-barrier material against moisture, ideal for processing on high-speed equipment, enhancing performance and productivity.
Technical information
- Non-toxic.
- UV protection (upon customer request).
- Maximum transmittance of 10% in the 290 – 450 nm range (applicable only to certain colors).
- Quality certificate for each batch.
- Sealable with aluminum.
- FDA DMF# 17508.
- Enhanced productivity on high-speed equipment.
- 250 – 500 μm
- Upon costumer request.
PVdC coating transmissions:
PVdC (g/m2): | 32 | 40 | 60 | 90 | 120 |
WVTR*: | 1.4 max | 0.8 max | 0.6 max | 0.4 max | 0.3 max |
*g/m2/day @ 38°C, 90%RH
Supopharmaplami
Clear and color PVC/PE film for suppositories:
Description
The qualities of these films allow them to be processed in thermoforming equipment to obtain blister packs usable as primary packaging for suppositories, which, thanks to their polyethylene layer, offer excellent heat sealing.
Technical information
Pharmaplami Premium Trilaminar
High-barrier Tri-layer PVC/PE/PVdC film in clear and colored.
Description
Its PE sealing layer and the added moisture protection from PVdC make this material ideal for thermoforming blister packs on high-performance equipment.
Technical information
- Non-toxic.
- UV protection (upon customer request).
- Maximum transmittance of 10% in the 290 – 450 nm range (applicable only to certain colors).
- Quality certificate for each batch.
- Sealable with aluminum.
- FDA DMF# 17508.
- PVC clear 250 μm
- PE clear 25 μm
- PVdC coating 90/120 g/m²
- Upon costumer request.
PVdC coating transmissions:
PVdC (g/m2): | 90 g/m2 | 120 g/m2 |
WVTR*: | Consult with our sales technical advisors. | |
Pharmaplami Premium BI
Description
PVC film produced and specially designed to be processed in thermoforming equipment to produce blister packs suitable for injectable storage.
Technical information
- Non-toxic.
- UV protection (upon customer request).
- Maximum transmittance of 10% in the 290 – 450 nm range (applicable only to certain colors).
- Quality certificate for each batch.
- Sealable with aluminum.
- FDA DMF# 17508.
- 300 – 500 μm
- Upon customer request.
WVTR 5 g/m2/day max @ 38°C, 90%RH
Pharmaplami Premium MD
Clear and color PVC/PE film for monodose:
Description
Material manufactured with the highest quality to be processed in thermoforming and filling equipment, designed for single-dose packaging.
Technical information
- Non-toxic.
- UV protection (upon customer request).
- Maximum transmittance of 10% in the 290 – 450 nm range (applicable only to certain colors).
- Quality certificate for each batch.
- PE sealing layer.
- FDA DMF# 17508.
- 250 μm a 380 μm
- Upon customer request.
Seal strength: Minimum 0.7 Kg-f/in.
Pharmaplami Aclar ® S-160
Description
Transparent or colored film, recommended for pharmaceutical blisters, such as packaging for tablets, capsules, and others, where a good level of moisture barrier and excellent formability are required.
Provides a medium level of moisture barrier and, to a lesser extent, protection against oxygen and aromas. It offers good transparency and shine on both sides, as well as excellent slip properties and physical-mechanical properties, such as impact resistance.
Pharmaplami Aclar ® S-2000
Description
Transparent or colored film, recommended for pharmaceutical blisters, such as packaging for tablets, capsules, and others, where a good level of moisture barrier and excellent formability are required.
Provides a high degree of moisture barrier and, to a lesser extent, protection against oxygen and aromas. It offers good transparency and gloss on both sides, as well as excellent slip properties and physical-mechanical properties, such as impact resistance.
Pharmaplami Aclar ® S-3000
Description
Transparent or colored film, recommended for pharmaceutical blisters, such as packaging for tablets, capsules, and others, where a good level of moisture barrier and excellent formability are required.
Provides a higher degree of moisture barrier and, to a lesser extent, protection against oxygen and aromas. It offers good transparency and gloss on both sides, as well as excellent slip properties and physical-mechanical properties, such as impact resistance.
